LG3120e
LG3120e
Industrial Edge Computing LoRaWAN Gateway with 4G, eSIM, Wi-Fi, Serial and I/O
The LG3120e is a high-performance industrial edge LoRaWAN gateway designed for remote and distributed field deployments where traditional cabling is difficult, costly, or impractical. By merging server-grade processing power—featuring a quad-core 2.0 GHz CPU and 2 GB RAM— with the comprehensive E2C Field Suite, the LG3120e provides a native LoRaWAN ecosystem for rapid wireless networking.
Operating on RobustOS Pro (Debian 11), the LG3120e acts as a centralized intelligence hub that solves the "Last Mile" connection problem. It enables plug-and-play monitoring for outdoor and distributed assets, bridging the gap between isolated field sensors and cloud-based analytics without the need for complex cabling.
The Robustel Cloud Manager Service (RCMS) is a unified cloud-based platform designed for real-time monitoring and centralized management of industrial IoT devices. Fully compatible with Robustel routers and gateways, RCMS delivers an interactive geospatial dashboard that enables users to visualize device locations and track critical metrics such as data usage, signal strength, and network status. To ensure seamless operations, the platform facilitates over-the-air (OTA) updates for firmware, configurations, and applications, minimizing downtime while optimizing system performance.
Features
- Wireless Last Mile Connectivity: Built-in LoRaWAN connectivity enables rapid deployment across distributed or remote sites where cabling is costly or impractical.
- Zero-Touch Sensor Onboarding: Automatically recognizes LoRaWAN sensors with over 300 pre-built codecs, generating data points and semantic tags in seconds for true plug-and-play monitoring.
- Integrated LNS: Built-in LoRaWAN Network Server for centralized device management and real-time monitoring of wireless field assets.
- E2C Field Data Integration: Supports LoRaWAN, Modbus, OPC UA, and BACnet to normalize fielddevice data for edge processing and cloud integration.
- Visual Logic and Dashboard: Specialized Node-RED nodes and a built-in visualization engine for dragand- drop automation and local dashboards.
- Server-Grade Performance: A quad-core 2.0 GHz CPU and 2 GB RAM enable local data processing to help reduce cloud traffic and application latency.
- Industrial I/O Density: Includes 2 x RS-232/485, 2 x DI, and 2 x DO interfaces to reduce the need for external I/O modules.
- Introduction
- Application
- Specification
- Download
- Get A Quote
Introduction
The LG3120e is a high-performance industrial edge LoRaWAN gateway designed for remote and distributed field deployments where traditional cabling is difficult, costly, or impractical. By merging server-grade processing power—featuring a quad-core 2.0 GHz CPU and 2 GB RAM— with the comprehensive E2C Field Suite, the LG3120e provides a native LoRaWAN ecosystem for rapid wireless networking.
Operating on RobustOS Pro (Debian 11), the LG3120e acts as a centralized intelligence hub that solves the "Last Mile" connection problem. It enables plug-and-play monitoring for outdoor and distributed assets, bridging the gap between isolated field sensors and cloud-based analytics without the need for complex cabling.
platform designed for real-time monitoring and centralized management of industrial IoT devices. Fully compatible with Robustel routers and gateways, RCMS delivers an interactive geospatial dashboard that enables users to visualize device locations and track critical metrics such as data usage, signal strength, and network status. To ensure seamless operations, the platform facilitates over-the-air (OTA) updates for firmware, configurations, and applications, minimizing downtime while optimizing system performance.
Available Models
| Model | Supported Frequency Bands | Supported LoRa Frequency | Certifications | Order Code | Package Contents |
|---|---|---|---|---|---|
|
LG3120e-ABJAA-4L-A35GL EU |
4G: LTE FDD: B1/2/3/4/5/7/8/12/13/18/19/20/25/26/28/66 LTE TDD: B34/B38/39/40/41 3G: WCDMA: B1/2/4/5/6/8/19 2G: GSM: B2/3/5/8 |
EU868 | CE*, UKCA* | A015800001 |
1 x Gateway (B Code: B015800001) 1 x Wall Mounting Kit |
|
LG3120e-ABJAA-4L-A35GL EU |
4G: LTE FDD: B1/2/3/4/5/7/8/12/13/18/19/20/25/26/28/66 LTE TDD: B34/B38/39/40/41 3G: WCDMA: B1/2/4/5/6/8/19 2G: GSM: B2/3/5/8 |
EU868 | CE*, UKCA* | A015800002 |
1 x Gateway (B Code: B015800001) 2 x Cellular Antenna 1 x Wi-Fi Antenna 1 x LoRa Antenna 1 x Power Adapter 1 x Wall Mounting Kit |
|
LG3120e-ACJAA-4L-A35GL AU |
4G: LTE FDD: B1/2/3/4/5/7/8/12/13/18/19/20/25/26/28/66 LTE TDD: B34/B38/39/40/41 3G: WCDMA: B1/2/4/5/6/8/19 2G: GSM: B2/3/5/8 |
AU915 | RCM* | A015800003 |
1 x Gateway (B Code: B015800002) 1 x Wall Mounting Kit |
|
LG3120e-ACJAA-4L-A35GL AU |
4G: LTE FDD: B1/2/3/4/5/7/8/12/13/18/19/20/25/26/28/66 LTE TDD: B34/B38/39/40/41 3G: WCDMA: B1/2/4/5/6/8/19 2G: GSM: B2/3/5/8 |
AU915 | RCM* | A015800004 |
1 x Gateway (B Code: B015800002) 2 x Cellular Antenna 1 x Wi-Fi Antenna 1 x LoRa Antenna 1 x Power Adapter 1 x Wall Mounting Kit |
|
LG3120e-ADJAA-4L-A35GL NA |
4G: LTE FDD: B1/2/3/4/5/7/8/12/13/18/19/20/25/26/28/66 LTE TDD: B34/B38/39/40/41 3G: WCDMA: B1/2/4/5/6/8/19 2G: GSM: B2/3/5/8 |
US915 | FCC*, IC* | A015800005 |
1 x Gateway (B Code: B015800003) 1 x Wall Mounting Kit |
|
LG3120e-ADJAA-4L-A35GL NA |
4G: LTE FDD: B1/2/3/4/5/7/8/12/13/18/19/20/25/26/28/66 LTE TDD: B34/B38/39/40/41 3G: WCDMA: B1/2/4/5/6/8/19 2G: GSM: B2/3/5/8 |
US915 | FCC*, IC* | A015800006 |
1 x Gateway (B Code: B015800003) 2 x Cellular Antenna 1 x Wi-Fi Antenna 1 x LoRa Antenna 1 x Power Adapter 1 x Wall Mounting Kit |
|
LG3120e-AEJAA-4L-A35GL Asia |
4G: LTE FDD: B1/2/3/4/5/7/8/12/13/18/19/20/25/26/28/66 LTE TDD: B34/B38/39/40/41 3G: WCDMA: B1/2/4/5/6/8/19 2G: GSM: B2/3/5/8 |
AS923 | CE* | A015800007 |
1 x Gateway (B Code: B015800004) 1 x Wall Mounting Kit |
|
LG3120e-AEJAA-4L-A35GL Asia |
4G: LTE FDD: B1/2/3/4/5/7/8/12/13/18/19/20/25/26/28/66 LTE TDD: B34/B38/39/40/41 3G: WCDMA: B1/2/4/5/6/8/19 2G: GSM: B2/3/5/8 |
AS923 | CE* | A015800008 |
1 x Gateway (B Code: B015800004) 2 x Cellular Antenna 1 x Wi-Fi Antenna 1 x LoRa Antenna 1 x Power Adapter 1 x Wall Mounting Kit |
Application
Specification
System Architecture
| Operating System | RobustOS Pro |
|---|---|
| CPU | Quad-core ARM Cortex-A53@2.0 GHz |
| RAM | 2 GB LPDDR4 |
| Flash | 8 GB eMMC |
Cellular
| Supported Technologies | 4G/LTE, 3G, 2G |
|---|---|
| Antennas | 2 (MAIN + DIV) |
| Connector | SMA-K |
| SIM | 1 x Mini SIM (2FF) |
| eSIM | 1 x eSIM (MFF2); GSMA SGP.22 compliant; supports profile download/removal and typically up to 8 eSIM profiles |
Ethernet
| Ethernet Ports | 2 x 10/100 Mbps, LAN or WAN |
|---|---|
| Magnet Isolation Protection | 1.5 kV |
LoRa
| Antennas | 1 |
|---|---|
| Connector | SMA-K |
| Frequencies | US915 EU868 AU915 AS923 |
| Channel capacity | Supports up to 8 channels receiving data simultaneously |
Serial Port
| Serial Ports | 2 x RS-232/485 (software configurable) |
|---|---|
| Connector | 6-pin 3.5 mm terminal block with lock |
| Baud Rate | 300–115200 bps |
| Signal Definition | RS-232: TXD, RXD, GND RS-485: Data+ (A), Data- (B), GND |
Digital Input/Output
| DI/DO Ports | 2 x DI + 2 x DO, wet contact |
|---|---|
| Connector | 8-pin 3.5 mm terminal block with lock (DI/DO) |
| Absolute Maximum Voltage | +30 VDC |
| Absolute Maximum Current | 100 mA |
| Signal Definition | DI1+, DI1-, DI2+, DI2-, DO1+, DO1-, DO2+, DO2- |
Wi-Fi Interface
| Number of antennas | 1, supporting only 1T1R |
|---|---|
| Connector | RP-SMA-K |
| Standards | 802.11 a/b/g/n/ac/ax; supports AP and client modes |
| Frequency bands | 2.412–2.472 GHz (2.4 GHz ISM band) 5.15–5.825 GHz (5 GHz ISM band) |
| Signal Definition | DI1+, DI1-, DI2+, DI2- |
Other Interfaces
| TPM | TPM 2.0 |
|---|---|
| Reset Button | 1 x RST |
| LED Indicators | 1 x RUN, 1 x RSSI, 1 x MDM, and 1 x USR |
| microSD | 1 x microSD, supporting up to 2 TB |
| Watchdog | External |
| USB | 1 x USB 2.0 (host), Type A, 5 V, 500 mA 1 x USB 2.0, Type C, console port |
| RTC | Remains functional up to 5 days after power loss |
Power Supply & Consumption
| PSU Connector | 2-pin 3.5 mm terminal block with lock |
|---|---|
| Input Voltage | 12/24 VDC, 9–36 VDC Reverse polarity protection, surge protection |
| Power Consumption |
Idle: 1.5 W@12 V Max: 15 W@12 V |
| Recommended Power Supply | 12 V DC/1.5 A power adapter |
Physical Characteristics
| Ingress Protection | IP30 |
|---|---|
| Housing & Weight | Metal, 587 g |
| Dimensions | 49 x 105 x 128 mm |
| Installation Options | Desktop, Wall Mount and 35mm DIN Rail |
| Operating Temperature | -25 – +70°C |
| Storage Temperature | -40 – +85°C |
| Relative Humidity | 5 – 95% RH (non-condensing) |
Software Features
| LoRaWAN Protocols | V1.0.4 Class A/Class B/Class C |
| Network Protocols | PPP, PPPoE, ARP, VLAN, ICMP, NAT, TCP, UDP, DHCP, DNS, DDNS, NTP, HTTP, HTTPS, Telnet, SSH2, SMTP, Static Routing, etc. |
| VPN Tunnels | IPsec, OpenVPN, GRE, L2TP, PPTP, DMVPN, WireGuard |
| Firewalls | DMZ, anti-DDoS, Filtering (IP/Domain name/MAC address), Port Mapping, Access Control |
| Remote Management | RCMS, Web, CLI, SMS |
| Serial Port Protocols | Transparent, TCP Client/Server, UDP, Modbus RTU Gateway |
| SIM Management | Smart Roaming V3, Language, eSIM Management, E2C Field Suite |
| Optional Apps | Request on demand |
Software Development Kit (SDK)
| Supported Programming Languages | C, C++, Python, Java, Node.js, etc. (for users to develop own applications) |
| Flash available for SDK | 6 GB |
| RAM available for SDK | 1.5 GB |
Regulatory and Type Approvals
| Environmental | RoHS 2.0 |
| EMI |
EN 55032 Conducted Emission Class B EN 55032 Radiated Emission Class B |
| EMS |
EN 61000-4-2 (ESD) Level 3 EN 61000-4-3 (RS) Level 3 EN 61000-4-4 (EFT) Level 3 EN 61000-4-5 (Surge) Level 3, AC Mains Power Port; Level 3, Signal Ports EN 61000-4-6 (CS) Level 3 |
