EG5200
EG5200
Industrial edge computing gateway with Dual-SIM 5G or 4G LTE, 5x Gigabit LAN, Serial, Console, HDMI, Relay
The Robustel EG5200 is an industrial edge computing gateway that combines secure cellular backhaul with on-box processing in a cabinet-ready form factor. Built on RobustOS Pro (Debian 11), it supports Docker containers and Debian packages so you can run protocol bridges, buffering, and analytics at the edge alongside your equipment.
Five Gigabit Ethernet ports, HDMI for local display, and USB 3.0/Type-C expandability simplify integration of cameras, sensors, and peripherals; optional Wi-Fi 6 (AP/Client) adds high-density wireless where needed.
Connectivity is resilient with dual-SIM 5G/4G/3G/2G and Ethernet WAN plus link-backup, while an enterprise VPN suite (IPsec/OpenVPN/GRE/L2TP/PPTP/DMVPN) protects data in transit. Serial (RS-232/422/485) and dry-contact DI/relay outputs support common industrial workflows. Fleet operations scale through RCMS for monitoring, configuration, and updates.
The result: a powerful, open platform for reliable connectivity and practical edge workloads across factories, smart-grid sites, and roadside cabinets.
Features
- Industrial-grade 5G/4G/3G/2G cellular with global band support
- 1.6 GHz ARM processor + 32 GB eMMC storage for compute-intensive edge workloads
- Docker containerization with 50,000+ Debian-compatible package
- 5 x Gigabit Ethernet for industrial network backbone
- 2 x USB 3.0 Type-A + 1 x USB 2.0 Type-C for peripheral connectivity
- 1 x HDMI local display output + 1 x RJ45 console port (CLI)
- Optional Wi-Fi 6 (802.11ax) dual-mode AP/Client and Bluetooth 5.3
- 2 x software-configurable RS-232/422/485 for PLC/legacy device integration
- 2 x dry contact DI + 2 x relay outputs for simple monitoring and control
- Dual-SIM for redundant communications
- Multi-language SDK support (C/C++/Java/Python/Node.js) with open development toolchain
- Multi-protocol VPN (IPsec/OpenVPN/GRE/L2TP/PPTP/ DMVPN) and firewall
- RCMS (Robustel Cloud Management System) for large-scale device control
- Introduction
- Application
- Specification
- Download
- Get A Quote
Introduction
The Robustel EG5200 is an industrial edge computing gateway delivering global 5G/4G/3G/2G cellular connectivity and ARMv8-based processing. Its Debian 11 (bullseye) based operating system supports Raspberry Pi-compatible applications, while Docker enables containerized deployment in harsh environments. Integrated with RobustOS Pro - Robustel's self-developed OS - the gateway provides enterprise-grade security (VPN/IPsec, smart roaming) and SMS-based remote management.
Powered by a quad-core 1.6GHz Cortex-A53 CPU and a dedicated NPU (2.3 TOPS), the EG5200 accelerates machine learning inference for real-time edge AI workloads. Combining cellular routing with embedded computing, this ruggedized platform serves as a converged cellular router and embedded edge compute node for industrial automation, smart grid, and machine vision deployments.
The Robustel Cloud Manager Service (RCMS) is a unified cloud-based platform designed for real-time monitoring and centralized management of industrial IoT devices. Fully compatible with Robustel routers and gateways, RCMS delivers an interactive geospatial dashboard that enables users to visualize device locations and track critical metrics such as data usage, signal strength, and network status. To ensure seamless operations, the platform facilitates over-the-air (OTA) updates for firmware, configurations, and applications, minimizing downtime while optimizing system performance.
Available Models
| Model | Supported Frequency Bands | Certifications | Order Code | Package Contents |
|---|---|---|---|---|
|
EG5200-A5CAZ-NU Wi-Fi+BLE Global |
– | CE, RCM*, UKCA, CB, FCC, IC, TELEC, JATE | A012000010 |
1 x Gateway (B Code: B120002) 1 x DIN Rail Mounting Kit |
|
EG5200-A5CAZ-NU Wi-Fi+BLE Global |
– | CE, RCM*, UKCA, CB, FCC, IC, TELEC, JATE | A012000005 |
1 x Gateway (B Code: B120002) 2 x Wi-Fi Antenna 1 x Power Adapter 1 x DIN Rail Mounting Kit |
|
EG5200-A5AAZ-4L-A06GL GNSS Global |
4G LTE FDD: B1/2/3/4/5/7/8/12/13/18/19/20/25/26/28 4G LTE TDD: B38/39/40/41 3G: B1/2/4/5/6/8/19 2G: B2/3/5/8 |
CE, RCM*, UKCA, CB, FCC, IC, TELEC, JATE | A012000011 |
1 x Gateway (B Code: B120004) 1 x DIN Rail Mounting Kit |
|
EG5200-A5AAZ-4L-A06GL GNSS Global |
4G LTE FDD: B1/2/3/4/5/7/8/12/13/18/19/20/25/26/28 4G LTE TDD: B38/39/40/41 3G: B1/2/4/5/6/8/19 2G: B2/3/5/8 |
CE, RCM*, UKCA, CB, FCC, IC, TELEC, JATE | A012000006 |
1 x Gateway (B Code: B120004) 2 x Cellular Antenna 1 x GNSS Antenna 1 x Power Adapter 1 x DIN Rail Mounting Kit |
|
EG5200-A5BAZ-4L-A06GL Wi-Fi+BLE+GNSS Global |
4G LTE FDD: B1/2/3/4/5/7/8/12/13/18/19/20/25/26/28 4G LTE TDD: B38/39/40/41 3G: B1/2/4/5/6/8/19 2G: B2/3/5/8 |
CE, RCM*, UKCA, CB, FCC, IC, TELEC, JATE | A012000012 |
1 x Gateway (B Code: B120006) 1 x DIN Rail Mounting Kit |
|
EG5200-A5BAZ-4L-A06GL Wi-Fi+BLE+GNSS Global |
4G LTE FDD: B1/2/3/4/5/7/8/12/13/18/19/20/25/26/28 4G LTE TDD: B38/39/40/41 3G: B1/2/4/5/6/8/19 2G: B2/3/5/8 |
CE, RCM*, UKCA, CB, FCC, IC, TELEC, JATE | A012000007 |
1 x Gateway (B Code: B120006) 2 x Cellular Antenna 2 x Wi-Fi Antenna 1 x GNSS Antenna 1 x Power Adapter 1 x DIN Rail Mounting Kit |
|
EG5200-A5AAZ-5G-A25GL GNSS (optional) Global |
5G NR SA/NSA: n1/2/3/5/7/8/12/13/14/18/20/25/26/28/29/30/38/40/41/48/66/70/71/75/76/77/78/79 4G LTE FDD: B1/2/3/4/5/7/8/12/13/14/17/18/19/20/25/26/28/29/30/32/66/71 4G LTE TDD: B34/38/39/40/41/42/43/48 4G LTE LAA: B46 (only supports 2 x 2 MIMO) 3G: B1/2/4/5/8/19 |
CE, RCM*, UKCA, FCC, IC | A012000013 |
1 x Gateway (B Code: B120003) 1 x DIN Rail Mounting Kit |
|
EG5200-A5AAZ-5G-A25GL GNSS (optional) Global |
5G NR SA/NSA: n1/2/3/5/7/8/12/13/14/18/20/25/26/28/29/30/38/40/41/48/66/70/71/75/76/77/78/79 4G LTE FDD: B1/2/3/4/5/7/8/12/13/14/17/18/19/20/25/26/28/29/30/32/66/71 4G LTE TDD: B34/38/39/40/41/42/43/48 4G LTE LAA: B46 (only supports 2 x 2 MIMO) 3G: B1/2/4/5/8/19 |
CE, RCM*, UKCA, FCC, IC | A012000015 |
1 x Gateway (B Code: B120003) 4 x Cellular Antenna 1 x Power Adapter 1 x DIN Rail Mounting Kit |
|
EG5200-A5BAZ-5G-A25GL Wi-Fi+BLE+GNSS (optional) Global |
5G NR SA/NSA: n1/2/3/5/7/8/12/13/14/18/20/25/26/28/29/30/38/40/41/48/66/70/71/75/76/77/78/79 4G LTE FDD: B1/2/3/4/5/7/8/12/13/14/17/18/19/20/25/26/28/29/30/32/66/71 4G LTE TDD: B34/38/39/40/41/42/43/48 4G LTE LAA: B46 (only supports 2 x 2 MIMO) 3G: B1/2/4/5/8/19 |
CE, RCM*, UKCA, FCC, IC | A012000014 |
1 x Gateway (B Code: B120005) 1 x DIN Rail Mounting Kit |
|
EG5200-A5BAZ-5G-A25GL Wi-Fi+BLE+GNSS (optional) Global |
5G NR SA/NSA: n1/2/3/5/7/8/12/13/14/18/20/25/26/28/29/30/38/40/41/48/66/70/71/75/76/77/78/79 4G LTE FDD: B1/2/3/4/5/7/8/12/13/14/17/18/19/20/25/26/28/29/30/32/66/71 4G LTE TDD: B34/38/39/40/41/42/43/48 4G LTE LAA: B46 (only supports 2 x 2 MIMO) 3G: B1/2/4/5/8/19 |
CE, RCM*, UKCA, FCC, IC | A012000016 |
1 x Gateway (B Code: B120003) 4 x Cellular Antenna 2 x Wi-Fi Antenna 1 x Power Adapter 1 x DIN Rail Mounting Kit |
Application
Specification
System Architecture
| Operating System | RobustOS Pro |
|---|---|
| CPU | Quad core Cortex-A53, 1.6 GHz |
| RAM | 4 GB DDR4 |
| Flash | 32 GB eMMC |
| NPU | 2.3 TOPS |
Cellular
| Supported Technologies | 5G, 4G/LTE, 3G, 2G |
|---|---|
| Antennas |
5G: 4 LTE: 2 |
| Connector | SMA-K |
| SIM | 2 x Mini SIM (2FF) |
Ethernet
| Ethernet Ports | 5 x RJ45, 10/100/1000 Mbps |
|---|---|
| Magnet Isolation Protection | 1 KV |
Serial Port
| Serial Ports | 2 x RS-232/RS-422/RS-485 (software configurable) |
|---|---|
| Connector | 2 x 5-pin 3.5 mm terminal block |
| ESD Protection | 8 KV air, 4 KV contact |
| Baud Rate | 300 bps to 115200 bps |
| Signal Definition |
RS-232: TXD, RXD, GND, CTS, RTS RS-422: RX+, RX-, TX+, TX-, GND RS-485: Data+ (A), Data- (B), GND |
Console Port
| Console Port | 1 x RS-232 |
|---|---|
| Connector | RJ45 |
| Baud Rate | 115200 bps |
| Signal Definition | TXD, RXD, GND |
Digital Input
| DI Ports | 2 x DI, wet contact |
|---|---|
| Connector | 4-pin 3.5 mm terminal block |
| Absolute Maximum VDC | +30 V DC |
| Absolute Maximum ADC | 100 mA |
| Signal Definition | DI1+, DI1-, DI2+, DI2- |
Relay Output
| Relay Ports | 2 x Relay Output |
|---|---|
| Connector | 6-pin 3.5 mm terminal block |
| Absolute Maximum VDC | +48 V DC |
| Absolute Maximum ADC | 100 mA |
| Signal Definition | NC1, NO1, COM1, NC2, NO2, COM2 |
Wi-Fi (Optional)
| Wi-Fi Antennas | 2 (Wi-Fi 0 + Wi-Fi 1) |
|---|---|
| Connector | RP-SMA-K |
| Standards | IEEE 802.11a/b/g/n/ac/ax, supporting AP and Client modes |
| Frequency Bands |
2.412 ~ 2.472 GHz (2.4 GHz ISM band) 5.15 ~ 5.825 GHz (5 GHz ISM band) |
| Security | WPA, WPA2, WEP, WPA3 |
| Encryption | AES, TKIP, WEP64 |
Bluetooth (Optional)
| Bluetooth Antennas | 1 (Multiplexing Wi-Fi antenna) |
|---|---|
| Connector | RP-SMA-K |
| Standards | Bluetooth 5.3 |
GNSS/GPS (Optional)
| GNSS Antennas |
5G: N/A 4G: 1 |
|---|---|
| Connector | SMA-K |
| Technology | GPS |
Other Interfaces
| Reset Button | 1 x RST |
|---|---|
| LED Indicators | 1 x RUN, 1 x Signal, 1 x USR, 1 x MDM |
| Watchdog | External |
| USB |
2 x USB 3.0 (HOST), Type A, 5 V, 900 mA 1 x USB 2.0 (OTG), Type C |
| HDMI | 1 x HDMI 2.0 |
| SD-Card | 1 x MicroSD |
Power Supply & Consumption
| PSU Connector | 2-pin 3.5 mm terminal block with lock |
|---|---|
| Input Voltage | 12/24/48 V DC, 9 ~ 60 V DC, reverse polarity protection, surge protection |
| Power Consumption |
Idle: 6.5 W@12 V Max: 15 W@12 V |
| Recommended Power Supply | 24 V DC/2 A power adapter |
Software Features
| Network Protocols | PPP, PPPoE, TCP, UDP, DHCP, ICMP, NAT, HTTP, HTTPS, DNS, NTP, SMTP, Telnet, ARP, VLAN, SSH2, DDNS, etc. |
|---|---|
| VPN Tunnels | IPsec, OpenVPN, GRE, L2TP, PPTP, DMVPN |
| Firewalls | DMZ, anti-DDoS, Filtering (IP/Domain name/MAC address), Port Mapping, Access Control |
| Remote Management | RCMS, Web, CLI, SMS |
| Serial Port Protocols | Transparent, TCP Client/Server, UDP, Modbus RTU to TCP |
| SIM Management | Smart Roaming |
| Optional Apps | L2TP, PPTP, DMVPN, VRRP, QoS, SNMP, Language, RCMS, Dynamic Route, Captive Portal, Modbus Master, TR069, Edge2Cloud, etc. |
Software Development Kit (SDK)
| Supported Programming Languages | C, C++, Python, Java, Node.js, etc. (for users to develop own applications) |
|---|---|
| Flash Available for SDK | 30GB |
| RAM Available for SDK | 2.5GB |
Regulatory and Type Approvals
| Environmental | RoHS 2.0 |
|---|---|
| EMI |
EN 55032 Conducted Emission Class B EN 55032 Radiated Emission Class A |
| EMS |
EN 61000-3-2 (Harmonic Current) EN 61000-3-3 (Voltage Flicker) EN 61000-4-2 (ESD) Contact Level 3, Air Level 3 EN 61000-4-3 (RS) Level 3 EN 61000-4-4 (EFT) Level 3 EN 61000-4-5 (Surge) Level 3 EN 61000-4-6 (CS) Level 3 EN 61000-4-11 (Dips) Class 3 |
